Self Harvester Combine SC 9500 Deluxe

SC 9500 Deluxe Self Propelled Combine Harvester is built with utmost reputation for what is important to farmers when it comes to harvesting, such as capacity, fuel efficiency, grain quality, low grain loss, reduced compaction and in field service availability. Panesar SC 9500 is a Self Propelled Multicrop Combine Harvester with Straw Walker Technology featuring diesel engines that are noted for the extraordinary power and reduced fuel consumption, while also complying with today's stringent emissions standards.

SC 9500 Deluxe Self Propelled Combine Harvester is built with utmost reputation for what is important to farmers when it comes to harvesting, such as capacity, fuel efficiency, grain quality, low grain loss, reduced compaction and in field service availability. Panesar SC 9500 Deluxe is a Self Propelled Multicrop Combine Harvester with Straw Walker Technology featuring diesel engines that are noted for the extraordinary power and reduced fuel consumption, while also complying with today's stringent emissions standards.

A.Engine Ashok Leyland
Model HGETIC3RD22
Power 101 HP at 2200 RPM
No. of Cylinder Six
Air Cleaner Dry
Cooling System Water Cooled
Straw Walker
No. of Straw Walker 5
NO. Of Steps 6
Length 3850 mm
Width 235 mm
Type
Front (18.4-30) 14pr
Rear (9.00-16) 16pr
Battery
No. of Batteries 2
Capacity & Rating of each 12V, 88Ah
Cleaning Sieves
Upper Sieve (LxB) 1216 x 1575 (62") + 1216 x635 (25")
Lower Sieve (LxB) 1216 X 1575 (62")
Fuel Tank (Ltr) 310
Main Dimensions In Workin / In Transport
Length (mm) 8534/12000
Width (mm) 6300/3250
Height (mm) 3730/3730
Ground Clearance (mm) 465
Weight (Kgs) 8720
